Packing size (mm)：Finished length: 150-300mm, width 130-200mm, height 80-100mm (more specifications can be customized)

Packing speed (lift/min)：10-60 packets/min

Packaging material：Roll film bag PE double-sided heat sealing film (recommended), a variety of heat sealing composite film

Air source：Approx. 0.6~0.7Mpa (Customer prepares its own air source)

Equipment power (KW)：The motor power is 11KW and the heating power is about 3KW

Power source：380V± 5%, 50Hz

Machine weight：3500kg

Overall dimension：Length 5048mm, width 1475mm, height 1585mm

The Host Adopts 9-axis Huichuan Sv635 Series Servo Independent Drive, Fast Response Speed, Accurate Action;

The Control System Is Equipped With Huichuan Ac703 Series Controller And Huichuan High Resolution Servo,

High-speed Running Performance Is More Stable;

 Large Lcd Touch Screen Display And Parameter Setting, Easy To Replace Specifications,

The Main Adjustment Parts Are Marked With Scale, Such As Film Film Position;

Compact Structure, Small Footprint, Convenient To Connect The Production Line;

Bag Making And Final Sealing Are Controlled By Delta Temperature Control Module System Heating Tube.

The Stable Deviation Is Plus Or Minus 1° At High Speed To Ensure That Each Bag Can Be Completed;

Pneumatic Parts Are Made Of Japan Smc, Airtic Brand, And Moving Parts Are Made Of Japan Nsk\thk Brand;

Production Status And Fault Automatic Tracking And Alarm System, And Through The Touch Screen Real-time Display;

Implement Interactive Operation.
