Model：ZB690F

Packing speed：23 bags / min

Bundle max range：L：720mm W：160～480mm H：90～250mm（Max height of single layer 135mm）

Bag material：M-shaped pre-made bag with vent hole

Bag stocks：2 bag stocks , automatic switch, each bag store 300 pcs pre-made bags

Overall dimensions：L：10340mm    W：2700mm    H：1800mm ( including feeding line and discharge part)

Power：Single installed power: 22KW, using power: 20KW

Power supply：380V±10%, 50Hz±5%,control voltage DC 24V

Air supply：0.5-0.7Mpa, 350L/ min

Weight：About 4000 kg

Noise：< 80 dB

ZB690F multi-function roll paper bag packaging machine adopts PLC and servo motor control,

the whole machine with reasonable design, fine processing, using domestic and foreign famous brand components,

with convenient configuration and reliable,

mature and stable performance, wide applicability characteristics;

The whole machine is composed of several parts, such as bag conveying,

material feeding, bag opening, bag pushing, sealing and negative pressure system. Among them,

bag conveying mechanism , material feeding mechanism,

bag pushing mechanism and upper suction bag  are driven by servo,

and other conveying mechanism of the equipment is driven by motor.
