Jumbo roll width (mm)：2850(mm)

Production speed (log/min)：10 logs/min

Max jumbo roll diameter (mm)：1500mm

Punch knife structure：Spiral cutter

Drive mode：Each part unit is controlled independently

Air source：0.5-0.8Mpa

Voltage：380V

Gram weight：15-30gsm

Raw material layers：1-4 layers

Machine power (kW) ：88.49KW

Imported motion controller control; Large-screen true color man-machine interface operation; 10 inverter independent drive of

the same server; International advanced technology such as integrated control of machine and photoelectricity, automatically

detect and adjust each action of the production line, so that the whole production line can reach the best working condition;

It can be equipped with edge pattern unit, embossing unit, gluing and laminating unit and printing unit to produce kitchen paper

and hand towel paper with various patterns and types;

Flexible assembly line: optional connecting conveyor belt, log-saw, single roll packaging machine, bundle packaging machine,

intelligent automatic box packing machine, storage rack, embossing group and other differentiated automatic production lines;

The width of raw materials of this model is optional: 2850mm;

The rear frame adopts pneumatic cloth function, which greatly reduces the labor intensity of workers;

Equipped with a frequency conversion speed regulating device to control the paper output speed, adjust the paper output

speed according to different base papers, set the speed of the interface, and operate

It is fast, simple, has a wider range of adaptation, and has high paper output stability;

Rewinding length: controlled by touch screen, the adjustment of rewinding length can be realized by adjusting the number of

punching sections (can be adjusted in a single sheet): the control accuracy of the number of sections can reach +/-1 section;

Imaginary tangent pitch adjustment, level adjustment, through HMI parameter setting; 20CM-60CM, pitch control accuracy

head +/-3mm; Automatic induction knife shaft protection system for broken cloth, when there is cloth wrapping and broken

cloth, the punching knife will be automatically disengaged.
