Packaging Speed：≤35packs/min

Equipment Dimensions：4460*3700*1870（mm）(L * W * H)

Equipment Weight：3500KG

Equipment power：25KW

Power Requirements：4P380V (3-phase 4-wire system)

Air Source Requirements：0.5 - 0.8 MPa (to be provided by the customer)

Packing specification：length of sealing line 120-420mm;Product length 200-550mm,Product height 100-230mm

Packaging bag material：PE and other European-stylepre-made bags with double-sided heat sealing function

pre-made bag stock：6 bag storage warehouses are switched in cycles

The equipment is fully servo-driven, featuring high precision, speed and stability;

The equipment connects to the main machine and can rotate products conveyed from the main machine by 90 degrees.

Equipped with an extra-large LCD touch screen for display and parameter setting,

making it more convenient to change specifications;the main adjustment points are equipped with a scale display.

By using the feather plate insertion type receiving, it ensures that the products can be stacked vertically without toppling over.

Equipped with automatic and manual discharge ports, which can be freely switched according to production requirements.
