Model：ZX660B

Packing speed：5-15ctns/min

Specification：L：270-650mm    W：180-500mm    H：120-450mm

Air supply：0.5-0.7Mpa

Carton quantity：100-150 pieces(three layer corrugated paper), can be customized

Packaging material：Corrugated carton

Power type： 380V  50Hz

Machine weight：3300KG

Overall dimensions：L：7900mm    W：3200mm    H：2600mm

Total power：15Kw

Noise：＜80dB

The machine structure is compact, can be configured according to the production needs of material,

to meet the different needs of customers, the equipment has a simple structure, stable and reliable,

convenient maintenance and other characteristics;

The equipment has automatic and accurate box delivery, automatic alarm or stop when the box is missing;

When the equipment stops, the material automatically stops conveying, which is convenient for the staff to solve the problem.

Equipment mechanical mechanism with overload protection function and shutdown, if the equipment overload protection,

after manual reset overload mechanism, button reset should be able to automatically restore the phase of the servo

control system (slow return to the origin);

Sealing part is sealed with adhesive tape to ensure smooth and beautiful sealing;

Manual and automatic selection functions can be set in the touch screen for each cylinder action;

All moving parts should be marked with safety protection;

The control line shall use multi-core × 1.5mm ² and above cable, the signal line shall use non-joint multi-core ×0.75mm²

and above shielded cable, the operation screen is arranged on the same plane position of the operation side and the

safety door, the electric control cabinet is fixed on the host machine, the wiring is reasonable and convenient for maintenance;

Replacement tape needs to stop the machine manual replacement;

There are certain requirements for the quality of the carton used; Compared with the same type of packing machine in the

market: 1. The packing layout of the manipulator is flexible and has strong applicability. 2. Easy to change production

and adjust specifications. 3, small footprint, save space for customers.
