Packing film roll max diameter：ф600mm

Packaging film roll paper core：φ76-80mm

packaging film thickness：0.05mm-0.12mm

packaging film material：PE double-sided heat sealing film (recommended), a variety of heat sealing composite film

Production speed：35-60 packs/min (depending on product characteristics)

Power：11KW

Host heating power：3.0kW

Product packaging specifications：L:250 mm-350 mm W:150 mm-200 mm H:80 mm-100 mm

Machine weight：3000KG

Pass rate： ≥97%

Overall dimensions：7000mmx1520mmmx1600mm(length X width X height)

Power supply type：380V(3-phase 4-wire)

Compressed air consumption：6kg/cm2 0.45m3/min

The material is sent to the pusher mechanism by frequency conversion motor, and the pusher mechanism is used

to stably separate each product with the same service motor:

When no product enters, the pusher mechanism will operate normally, and the equipment will not take the

bag and waste the packaging:

The main machine adopts 9-axis Inovance SV635 series independent drive to the strand, with fast response and accurate action;

The control system is equipped with Huichuan AC703 series controller and Huichuan high-resolution server,

which makes the high-speed operation performance more stable;

Large LCD touch screen display and parameter setting, easy to change specifications,

main adjustment parts are marked with scales, such as film position

Delta's temperature control system and heating tube control are used to control

the bag making and final sealing, and the stable deviation is at plus or minus 3 high

speed to ensure that each bag can be made at high speed;

Pneumatic parts adopt Japanese SMC, AIRTAC brand, and moving parts adopt

Japanese NSKTHK brand:

The side pressure mechanism of the final sealing part is easily adjusted;

The discharge mechanism of the final sealing part is easily adjusted.
