Packaging film roll max diameter：φ550mm

Packaging film roll paper core：φ76-80mm

packing film thickness：0.05mm-0.08

packaging film materia：PE double-sided heat sealing film (recommended), various heat sealing composite films

Packing speed：45-120Packs/min (depending on product characteristics)

Motor power：10Kw

Host heating power：3.0Kw

Product packaging(LxWxH)：L：65mm-120mm  W：40mm-60mm  H：20mm-50mm

Machine weight：3000Kg

Pass rate：≥98%

Overall Dimensions：7400mmx1000mmx2200mm (LxWxH)

Power supply type ：4P380V (3-phase 4-wire)

The material is sent to the pushing mechanism by frequency conversion motor,

and the servo motor of the pushing mechanism is used to stably separate each product;

When no product enters, the pusher mechanism will operate normally, and the equipment will not take the bag and waste the bag;

The main machine adopts 10-axis Mitsubishi J4 series servo independent drive, with fast response speed and accurate action;

The control system is equipped with Mitsubishi Q series PLC, motion CPU and Mitsubishi J4 high-resolution servo,

which makes the high-speed operation performance more stable;

Extra-large LCD touch screen for display and parameter setting, easy to change specifications,

with scale markings on the main adjustment parts, such as the film position;

The bag making and final sealing are controlled by Omron high-end temperature control system and heating tube,

and the stable deviation is at plus or minus 1° high speed

Ensure that each bag can be made during operation;

The pneumatic parts adopt the Japanese SMC brand, and the moving parts adopt the Japanese NSK/THK brand;

The final sealing part molding mechanism is easy to adjust;

The side pressure mechanism of the final sealing part is easy to adjust;

The final sealing part discharge mechanism is easy to adjust.
