Model number：WP-30 / WP-50

Maximum load (KG)：25KG / 45KG

Working radius (mm)：1680mm / 1780mm

Maximum palletizing time (pcs)：≦12PCS/min / ≦8PCS/min

Maximum stacking height (mm)：≦2350mm  / ≦2450mm

Repeated positioning accuracy (mm)：±0.04mm

Pallet arrangement：Manually, one on the left and one on the right

Maximum fitting tray (mm)：1200*1000mm

Equipment appearance size (mm)：L1732*W1200*H2490mm / L1732*W1300*H2615mm

Size of wooden box (mm)：L2200*W1450*H1900mm / L2250*W1450*H1900mm

Maximum power (KW)：3.5KW

Reference air consumption：240-460L/min

Power supply requirement：220V±10%，50Hz±5%

Gas supply requirement：0.5～0.7Mpa

Communication mode：EtherCAT interface, extended I0

IP level：IP54

Temperature range：0-50°C

Machine weight (KG)：约600kg / 约650kg

Simple operation, support a variety of palletizing formulas,

fool-like operation, easy to learn and understand;

Low energy consumption and low operating cost;

Small footprint, flexible and can be moved at will;

Safe and convenient, no need for guardrails.
