Packing speed (box/min)：5-12boxes/min

Packing specifications：length 270-650mm, width 180-500mm, height 150-600 mm

Air supply：0.5~0.7 Mpa

Number of storage containers：100-150 pcs (three-layer corrugated paper, can be customized upon request)

Machine power (kW)：12 kW (including the material handling line)

Packing material：Corrugated cardboard

Power supply type：380V  50Hz

Machine weight (kg)：about 4000 kg (including the material handling line)

Overall dimensions (mm)：L: 8150mm, W: 3600mm, H: 2300mm (including material handling line)

The structure of the whole machine is compact, and the material can be configured according to the production needs to meet the different needs of customers, and the equipment has the characteristics of simple structure, stable and reliable, and convenient maintenance;

The equipment has automatic and accurate box feeding, and the box is missing and automatically alarms or stops;

When the equipment fails, the material will automatically stop conveying, which is convenient for the staff to solve the problem. If the equipment has overload protection, after the manual reset of the overload mechanism,

the button reset should be able to automatically restore the phase of the servo control system (slow return to the origin);

The sealing part is sealed with tape to ensure that the sealing is smooth and beautiful;

The action of each cylinder can be set in the touch screen manual and automatic selection function;

All moving parts need to be marked with safety protection signs;

The control line needs to use multi-core x1.5 mm2 and above cables, the signal line adopts multi-core

x0.75mm2 and above shielded cables without joints, the operation screen is set on the operation side

and the position of the same plane as the safety door, the electric control cabinet is fixed on the host,

the wiring is reasonable, and it is convenient for maintenance; Replacing the tape needs to be stopped

and replaced manually;

There are certain requirements for the quality of the cartons used;

Compared with the same type of packing machine in the market:

1. The manipulator packing layout is flexible and has strong applicability.

2. It is convenient to adjust the specifications of production change.

3. It occupies a small area and saves space for customers.
