Jumbo roll width (mm)：2050(mm)

Production speed (log/min)：10 logs/min

Max jumbo roll diameter (mm)：1500mm

Punch knife structure：Spiral cutter

Drive mode： Each part unit is controlled independently

Air source：0.5-0.8Mpa

Voltage：380V

Gram weight：15-30gsm

Raw material layers：1 layer

Machine power (kW)：68.49KW

Imported motion controller control: large-screen true color man-machine interface operation; Same strand + inverter independent drive; International advanced technology such as mechanized photoelectric control automatically detects and adjusts each action of the production line, so that the whole production line can reach the best working condition;

It can be equipped with embossing unit, using steel to wool pressing method, and the flower can be heated by oil or electricity;

Flexible line assembly: optional connecting conveyor belt, automatic cloth cutting machine, heat shrink packaging machine,

labeling machine, card inserting machine, intelligent automatic packing, storage rack, embossing group, etc. to form a differentiated

automatic production line;

The width of raw materials of this model is optional: 2050mm;

The rear frame adopts pneumatic cloth function, which greatly reduces the labor intensity of workers.

Equipped with frequency conversion speed regulation device to control the speed of dispensing, adjust the

speed of dispensing according to different original fabrics, set the speed of the interface, the operation is fast

and simple, the adaptation range is wider,

and the stability of dispensing is high.

 Rewinding length; Through the touch screen control, the adjustment of the rewinding length can be realized by

adjusting the number of punching sections (which can be adjusted in a single sheet): the control accuracy of

the number of sections can reach +/- 1 section;

Imaginary tangent pitch adjustment, step-by-step adjustment, through HMI parameter setting; 20CM-60CM,

pitch control accuracy is +/-3mm; Automatic induction knife shaft protection system for broken cloth,

when there is cloth wrapping and broken cloth, the punching knife will be automatically disengaged
