production speed：140Packs/min

Packing size：95-200mmx80-110mmx30-100mm (LxWxH)

Air source：0.5-0.8Mpa

Heating power：5.4Kw

Motor power： 15Kw

Packaging material：CPP (Two-Sided Heat Sealing Film)

Power supply type：380V 50Hz

Machine weight：about 3000Kg

Overall Dimensions： 6100mmx3790mmx1720mm (LxWxH)

ZB300H automatic high-speed facial tissue packaging machine is controlled by industrial computer, equipped with 16 sets of

absolute servo system and 2 sets of frequency conversion system. Precise action, stable operation, high degree of automation,

more intelligent, and high scalability;

The electronic handwheel is used instead of the manipulator wheel (the first in the industry), which is easy to

debug and accurate to position;

Open mechanical structure design, installation, commissioning, operation and maintenance are more convenient;

Backward turning type baling structure, simple adjustment, stable and beautiful packaging effect;

Through photoelectric intelligent detection and tracking, it can solve the problems of continuous package, empty package,

multi-package and so on for customers, improve quality and efficiency, and greatly reduce material loss;

The servo film release system is adopted, and the resistance ruler is used for feedback tracking, which is accurate and

stable in film release,

which effectively avoids the unstable packaging caused by the shaking of the film roll;

Intelligent man-machine interface, with the function of saving the formula with one click, greatly improves the efficiency of

production modification and reduces the waste of packaging materials;

It has a variety of optional functions to meet the needs of different customers: such as Internet of Things networking,

visual inspection, automatic deviation correction of film rolls, various special-shaped tearing notches, etc.;

The anti-drifting paper feeding method is adopted, and the feeding is more stable;

The air cooling function of discharging can improve the cooling effect of the sealing and ensure the aesthetics of the sealing.
