Jumbo roll width(mm)：1650/2250(mm)

Production speed (logs/min)： 80-100 m/min or 10-14 logs/min

Max jumbo roll diameter (mm)：1500mm

Face cutter structure：Spiral cutter

Drive mode：Each part unit is controlled independently

Air source：0.5-0.8Mpa

Voltage：380V

Gram weight：35-100gsm

Raw material layers：1 layer

Machine power(kW)：68.49/86.49KW

Using motion control technology and HMI control system, full servo execution paper separation mechanism,

 independent drive control and tension control of each part, and the quality control of finished products is guaranteed;

It can be equipped with automatic cloth splicing, cloth storage rack, etc., to improve the production efficiency of the whole line;

The width of raw materials of this model is optional: 1650mm, 2250mm;

The rear frame adopts pneumatic cloth loading function, which greatly reduces the labor intensity of workers;

Equipped with a frequency conversion speed regulation device to control the speed of dispensing,

 adjust the speed of dispensing according to different original fabrics, set the speed of the interface,

the operation is fast and simple, the adaptation range is wider, and the stability of the paper output is high.

The inverter adjusts the speed of dispensing, and adjusts the speed of dispensing according to different original fabrics,

and the whole machine is controlled by the human-machine interface, which is fast, simple, with high stability

and wide range of application;

Spiral transverse single-cutter roller set: spiral cutter roller set: stable cloth breakage, long tool service life,

and with cloth breakage, cloth wrapping detection, automatic knife lifting system. Ensure the implementation of

all-round protection in the process of machine operation, and effectively protect the face knife and bottom knife;

The folding roller used: the composite processing of imported special materials greatly improves the rigidity

and hardness of the roller body, and the method of suction at both ends is adopted to shorten the length of

the suction roller surface, ensure sufficient vacuum adsorption, and greatly improve the accuracy and stability of

the folding product; Make the end face of the semi-finished product more neat and flat.

Using double air cover vacuum adsorption system, folding suction disc and cutting knife suction disc are

independently controlled to provide negative pressure, according to the adjustment of flow rate and negative pressure,

find the most suitable balance value, can effectively reduce energy consumption, reduce vacuum pump motor power;

Equipped with a material protection device to ensure that the automatic stacking can be applied to any material,

which solves the problem of affecting the smooth production of the machine due to the raw materials being too thin,

too light, too long fiber, too much static electricity, etc., and ensures the high quality and uniformity of the product.
