Equipment model：ZX660R

Packing speed (box/min) ：5-12 boxes/min (depending on the product)

Carton size：L: 270-550mm, W: 160-400mm, H: 120-400 mm

Sealing method：Tape sealing (48mm, 70 mm width optional)

Air consumption：0.5~0.7 Mpa, Air consumption ： 200 L/min (the buyer prepares the air source by himself)

Equipment power (kW)：14 kW (including material handling line)

Box material：Corrugated cardboard

Power supply type：380V ± 10%, 50 Hz ± 5%, control voltage DC 24V

Machine weight (kg)：3000kg (including the material handling line)

Host size (mm) ：L: 7750mm W: 4600mm H:2650mm (including material handling line)

This equipment is precisely controlled by servo and PLC. It has high positioning accuracy,

stable and reliable operation, and small repetitive positioning errors.

The operation is highly flexible, allowing for quick switching of product specifications through programs,

and it can be adapted for multi-variety production.

The material sorting and packaging are integrated. The mechanical hand automatically completes sorting,

arranging, grasping, and packaging, reducing manual intervention.

The running speed can be adjusted, with high efficiency. The servo responds quickly and

 can match the production rhythm of high-speed production lines.

The structure is compact and occupies a small area.

The mechanical hand replaces traditional mechanical link rods, and the layout is more flexible.

Fault self-diagnosis and alarms are available.

The PLC monitors the operating status in real time, facilitating quick troubleshooting.

The human-machine interface is friendly. It is operated through a touch screen,

with parameter visualization, and is simple and easy to learn.

The operation is smooth, with low noise. The servo drive has no impact and causes little damage to the products and packaging.

It has strong scalability and can be connected to conveyor belts,

unpacking machines, sealing machines, and palletizing machines to form a fully automated packaging line.

High stability, long lifespan, suitable for continuous 24-hour industrial production, and low maintenance cost.
