packaging film thickness：0.05mm-0.07mm;

packaging film material：PE double-sided heat sealing film (recommended), various heat sealing composite films

Packing speed：30-60Packs/min (according to product characteristics)

Motor power ：11Kw

Host heating power：3.0Kw

Product packaging length、 width 、height ：L:120mm-300mm W:70mm-110mm  H:70mm-110mm

Machine weight：3000Kg

Pass rate：≥98%

Overall dimensions：5000mmx1000mmx2200mm (LxWxH)

Power supply type：4P380V (3-phase 4-wire )

Compressed air consumption：6kg/cm2  0.45m3/min

Adopt 10-axis Mitsubishi J4 series servo independent drive, fast response speed and accurate action;

The control system is equipped with Mitsubishi Q series PLC, motion CPU and Mitsubishi J4 high-resolution servo,

which makes the high-speed operation performance more stable;

Large LCD touch screen display and parameter setting, easy to change specifications;

It has the function of opening the bag detection, and the opening of the bag is not successful,

and the function of pushing the material is not pushed;

It has the function of incoming material detection, no material

does not take the bag, and the fan is automatically turned off for

a long time without material;
