Packaging film roll max diameter：Ф550mm

Packaging film roll paper core：Ф76-80mm

packaging film thickness：0.05mm-0.07mm

packaging film material：PE double-sided heat sealing film (recommended),

various heat sealing composite films

Packing speed：45-80Packs/min (depending on product characteristics)

Motor power：11Kw

Host heating power：3.0Kw

Product packaging L x W x H：L:100mm-200mm (PE film) 、W:70mm-110mm、H:25mm-100mm

Machine weight ：3000Kg

Pass rate：≥98%

Dimensions：7000mmx1000mmx2200mm (LxWxH)

Power supply type：4P380V (3-phase 4-wire)

Compressed air consumption：6kg/cm² 20.45m³/min

The material is sent to the pushing mechanism by frequency conversion motor, and the servo motor of the pushing

mechanism is used to stably separate each product;

When no product enters, the pusher mechanism will operate normally, and the equipment will not take the bag and waste the bag;

The material conveying mechanism has the function of automatic detection of ultra-high and ultra-long products;

Large LCD touch screen display and parameter setting, easy to change specifications;

Fully automatic material management unit, with the functions of material shortage acceleration and full material deceleration,

perfect docking with front-end automatic equipment;

The main engine adopts 11-axis Mitsubishi JE series servo independent drive, with fast response speed and accurate action;

The control system is equipped with Mitsubishi L series PLC, motion CPU and Mitsubishi JE high-resolution servo,

which makes the high-speed operation performance more stable;

Large LCD touch screen display and parameter setting, easy to change specifications, and the main adjustment parts

are marked with scales, such as the film position;

Bag-making and final sealing are controlled by Delta's temperature control module system, heating tube,

and stable deviation, ensuring that each bag can complete bag making when running at plus or minus 19 high speeds;

It has the function of detecting incoming materials, not taking bags without materials, and automatically

shutting down the fan if there is no materials for a long time; it is equipped with automatic deviation

correction device for packaging film (made in Germany).
