Model：ZB520P

Packing speed：80-120 Rolls/min

Packing size：D： 90-130mm L：90-130mm

Packing paper：W：360mm L：440mm

Packing paper material：17-26g(Sydney paper/copy paper)

Air supply：0.5-0.7Mpa

Motor power rate：13.2KW

Power supply type：380V 50Hz

Machine weight：About 4000KG

Machine dimension：L：2880mm    W：3050mm    H：1925mm

MAIN TECHNICAL FEATURES

The machine is with 14 absolute value servos control system and 1set of inverters. This makes the machine run

more precisely and system run very stable with high level of intelligence;

The machine is with electric jigger instead of mechanical jigger to convenient and precise operation;

The machine is equipped with film tension auto-adjusting device and inflatable shaft for fast and precise fim loading;

The machines has 4 working station to achieve the stable performance, tissue grabbing and inserting good effect;

The tangent line and pull off device is with our Independent intellectual property rights, It is not sensible to the

static electricity and can send paper film precisely;

The machine has the intelligent film pulling position calculating function. It can automatically adjust the paper

film position by just inputting the relevant parameters and greatly reduce the film changing time;

The machine has the formula in the HMI which makes the specification changing more fast;

The open type machine frame makes the machine operation, adjusting and maintenance more convenient.
