Model：SCD-175-1500 / SCD-190-2000

Stable speed：100-130m/min or 3-5 logs/min / 100-130m/min or 3-5 logs/min

Jumbo roll width：1480mm(Max) / 1920mm(Max)

Jumbo roll diameter：≤1500mm

Pulls setting range：200-500Pulls

Height range：200-400mm(Below 200mm should be specified in advance)

Open size：175mm (+1,-2)(If different, please specify) / 190mm (+1,-2)(If different, please specify)

Folded size：87.5mm (+1,-1)(If different, please specify) / 95mm (+1,-1)(If different, please specify)

Raw material requirements：2 plies13.5-18g/㎡,3 plies or 4plies, each ply gram weight 11-15g/㎡

Folding part motor power：5.5KW

Vacuum power：30KW / 37KW

Power type：380V 50Hz(If different, please specify)

Air supply：≥0.6MPa

MAIN TECHNICAL FEATURES:

SCD-175-1500/ SCD-190-2000 each part independent motor drive,vacuum adsorption, "V"

type staggered folding,alloy steel roller,fixed spiral knife to cutting tissue paper

Big touch screen adjusting pulls number and tension

High resolution servo operation,100% accurate counting
