Model：ZB530

Packaging size：Φ90-125mm     L 90-220mm

Packaging film   Film thickness：0.018mm—0.03mm

Packaging film   Film material：SPP Double-sided heat sealing film

Packing speed：230 Rolls/min

Power   Motor power：4.75KW

Power   Heating power：5KW

Power   Side hot heating power：7.2 KW

Total power：15 KW

Pass rate：97%

Pattern deviation：≤3mm

Overall operating efficiency：≥85%

Weight ：2200KG

Overall dimensions：L：4330mm    W：3450mm    H：1700mm

Power type：3phase 4wire , 380V 50Hz, control voltage DC24V

Air supply：250L/min

Noise：≤75dB

MAIN TECHNICAL FEATURES

New design which is more reasonable, compact structure, easier operation and saving more space.

Full servo motor control which assures more stable performance.

PLC control which assures the machine running more stable.

Different sizes paper roll can be changed quickly based on the related mould.
