Model：ZH120

Packing speed ：50-120 boxes/min

Configuration(Host+Manage part)：Main machine: 7 servo

Manage material part: 1 servo + 1 frequency conversion

(Finished product）L ：110-250 mm

(Finished product）W：90-120 mm

(Finished product）H：20-100 mm

Box quality requirements：The box should be pre-folded effect，250-350g/m2

Power type： 380V 50Hz

Motor power Main machine+Manage material part：4.55+0.52=5.07 KW

Total power about (Including spray glue machine)：10.02 KW

Overall dimensions(Including manage material part）：4525*2995*1840 mm

Compressed air    Air supply：0.6-0.8 Mpa

Compressed air    Air consumption：20 L/min

Machine net weight ：1200 KG

MAIN TECHNICAL FEATURES:

The whole machine adopts 7 servo drive, with independent control, feeding detection, glue

detection, empty box detection;

The machine adopts sheet metal structure, smooth design, beautiful, easy to operate;

The whole machine adopts motion controller, stable and reliable operation;

Touch screen display real-time operation data, formula automatic memory, switch product

storage function, easy operation;

Can be compatible with a variety of box specifications, easy to adjust;

Can choose glue spraying, code spraying, steel printing and other auxiliary functions;

Double servo pushing and feeding control, stable and accurate packing;

Multiple safety protection measures, fault self-diagnosis function, alarm display at screen.
