Model：ZB800

Film roll：Maximum diameter：φ600 mm        Film paper core：φ76-80mm

Film thickness：0.06mm—0.09mm

Film material：PE Double-sided heat sealing film (recommended), various heat sealing composite film.

Speed：30-45 packs/min(Depending on the product size)

Power：Motor power：11 Kw          Main heating power：3.0Kw

Specifications：L：100 mm -250 mm      W：100 mm -230 mm       H：70mm -100 mm

Machine weight：3000KG

Pass rate：≥97%

Overall dimensions：7000mm×1000mm×2200mm(L×W×H)

Power type：380V (3 Phase 4 line system)

Compressed air amount：6kg/cm2       0.45m3/min

Noise：≤75（db）

MAIN TECHNICAL FEATURES:

Auto feeding conveyorproduct;Standard machine:accurate action;during the high-speed operation;6,

Color mark sensor adopt SICK

1 Use frequency conversion motor into the feeding mechanism with the servo motor to stably separate each

2, When the push mechanism enters, the machine will not take bags or waste packaging bags;

3, The material conveying mechanism has the over-high and over-long automatic detection function

1 The main machine adopts 10-axis Mitsubishi JE series servo independent drive, fast response speed,

2, Control system is equipped with Mitsubishi L series PLC, sports CPU combined with Mitsubishi JE

high-resolution servo, high-speed operation performance is more stable;

3. Large LCD touch screen display and parameters setting, convenient to change the specifications, the main

adjustment parts are marked with the scale, such as the envelope envelope position;

4. The bag making and the final seal are controlled by the heating tube of the Delta temperature control

module system, and the stability deviation shall ensure that the bag making of each bag can be completed

5. Pneumatic parts adopt Japanese SMC brand, and sports parts adopt Japanese NSK\ THK brand;
