Model：ZB-600

Sealing mode：Side sealing system

Power supply：380V    50-60Hz

Packing speed：Depends on products length

Packing height：250mm

Packing width：430mm

Size limited：W + H≤550mm

Film：POF，PE center-folded

Max film size：W：700mm      280mm(OD)

Sealer power consumption：2.5 KW

Aire compressor：0.5Mpa

Machine material：Carbon steel

Machine dimension：L：2610mm   W：1450mm  H：1530 mm

Tunnel power：3phase 4wire , 380V 50Hz , control voltage DC24V

Shrink oven size：L:1500mm  W:600mm  H:300mm

Conveyor speed：40 m/min

Conveyor：Chains with rotating silicon coated rods

Power consumption：12 KW

Conveyor height：780 – 850 mm

MAIN TECHNICAL FEATURES:

This machine can pack long products. there is no limit of product length because of side sealing system;

Special durable alloyed sealing knife with anti-stick Teflon coats makes sealing strong and

has better performanceof heat conduction;

Side sealing line can be adjusted in the center of product or other desired position.
