Model：ZB680HN

Packing size：Max bundle length：500mm；Bundle width range：90~420mm；Bundle height range：90~310mm；

Packaging form：Single layer single row 3-6 bags,double row 6-12 bags;  two layers three layers.

Bag material：M-shaped PE OPP CPP pre-made bag with exhaust hole

Packing speed：Single layer ≤40 bags/min  Double layers ≤10 bags/min    Three layers ≤6 bags/min

Power supply：380V ± 5%, 50Hz 3 phase 4 wire,all control voltage is DC 24V

Air pressure：Bag material:M-shaped PE OPP CPP pre-made bag with exhaust hole

Power：Single installed power：28KW, Using power ：around 26KW

Safety：Machine adopts CE standard

Bag residue：25-30mm of waste material cut into the waste film box by automatic film absorption

Adopt motion controller and servo motor control, high degree of humanization, simple operation,

accurate positioning and more stable operation.
