Max length：720mm

Width：180-480mm

Height：90-240mm

Bundle package form：Lying rolls, 2-4 rows, 1-2 layers, 2-48 rolls，Standing rolls, 2-4 rows, 1-2 layers, 6-48 rolls

The bundle packagebag material is：M-type pre-made bags with exhaust holes (single-layer thickness of pre-made bags is 40-60μm,
exhaust hole diameter is 5-6mm) suitable for OPP, CPP, PE materials (materials must have double-sided heat sealing function,

handle holes are through holes, and the packaging bag has good static elimination and no sticking).

Design packing speed：25 bags/min

Working speed：10-20 bags/min

Power supply：380V ± 5%, 50Hz three-phase four-wire + ground wire, all control voltages use 24V DC

Air pressure：approx. 0.6–0.7 MPa (air source to be provided by the customer)

Equipment power：Single unit installed power 23KW, operating power approx. 21KW

Equipment safety：Safety markings in accordance with CE standards

Packaging bag scraps：25-30 mm scraps cut off from the seal are automatically sucked into the waste film box

MAIN TECHNICAL FEATURES:

Controlled by a motion controller, it uses 13 servo drive systems, offering high user-friendliness,

easy operation, precise positioning, and smoother operation;Features internal layering,

ensuring high-speed and stable material feeding;normal production power not exceeding 21 kW,

significantly lower than similar productsdomestically and internationally.and perfect sealing;

Low energy consumption, with the rated power of the entire machine not exceeding 23 kW and the

The heating control adopts a unique constant-temperature sealing control method to ensure flat

Sensors: Photoelectric sensors use Omron or SICK, ensuring the stability of equipment detection;
