Packaging capacity: 20-30 tons/hour

Measurement accuracy: ± 0.2%

Bag size: 500-1200 * 500-1200mm (length * width * height)

Measurement range: 250-1000kg/bag

Main power supply: AC380V ± 5%, three wire four wire system (TN-S)

Power: 5KW (tentative, adjusted according to configuration differences)

Total gas source: ≥ 0.6Mpa

Gas consumption: ≤ 1m ³/min (tentative, adjusted according to configuration differences)

Electronic sensor weighing, digital weight display controller, net weight measurement with high accuracy

Automatic start, automatic peeling, automatic air volume compensation

High precision, high-resolution ∑ - A type A/D conversion, internal A/D conversion rate>200 times/second

Complete dust removal and return air mechanism, no dust overflow during packaging, with environmental protection function

A unique negative deviation compensation device that can automatically compensate for negative deviations in packaging accuracy

Compensate for the negative deviation of this package until the packaging error reaches a positive deviation

Using PLC control, automatically complete actions such as bag clamping, loading, continuous measurement, and bag loosening

Can store 10 formulas, each with 9 cumulative weights and 6 cumulative package values

High performance anti vibration filtering technology to prevent errors caused by the vibration of the scale body
