Material type: granular material

Feeding method: gravity type

Packaging speed: 2-12 packs/minute

Packaging weight: 5-25kg

Bag size length: 500-900mm

Bag size width: 300-550mm

Power type: 380V 50HZ

Gas consumption: ≥ 0.6MPa 0.6m ³/min

Total power: 8.5KW

Dimensions: 3700 * 2300 * 5200mm

Sealing methods: seam sealing, heat sealing, edge wrapping

The unit employs an integrated modular design, comprising an automatic weighing and metering machine, a packaging

mainframe, an automatic bag feeder, and a sealing system. Depending on requirements, options include single/dual weighing

and high/low-speed weighing and metering systems.

The control system, equipped with AI-powered intelligent computation and self-learning capabilities, automatically adjusts

and optimizes parameters to ensure optimal speed and accuracy. It also performs automatic analysis and computation based

on accuracy feedback from the backend belt-type weighing system, enabling automatic parameter adjustments for the

metering system.

For different materials, options include granular material meters, powder meters, and ultrafine powder meters.

We offer both standard

and large-capacity automatic bagging systems to enhance bag storage capacity. The standard configuration includes

an automatic bag

length and height adjustment mechanism to accommodate

production requirements for various product sizes. For sealing, options include sewing machines, heat sealers, or a

combination of both for bag opening sealing.

The system also features fault diagnosis and assistance functions. Utilizing a multi-axis servo

system as the actuator, it provides automatic adjustment and synchronous control, along with

automatic parameter setting, enhancing equipment stability and facilitating operator handling and debugging. The system is

equipped with a full-color dual touchscreen human-machine interface, enabling operators to control and debug

the equipment from different locations. It also provides real-time status monitoring and data collection. Additionally,

it includes a remote assistance function that, with customer authorization, can automatically restore parameters,

modify programs, expand functions, and diagnose and resolve faults.
