Equipment model: GD60

Packaging capacity: 600-1200 packs/hour

Bag size Length: 600-1100mm Width: 400-600mm

Whole machine weight: 3800Kg

Total power: 15Kw

Gas source: ≥ 0.6MPa 1.5m ³/min

Power type: 380v 50Hz

Dimensions: 5000x3500x4900mm

The unit adopts an integrated modular design, consisting of an automatic weighing and measuring machine, a packaging host, and an automatic bag feeding machine;

According to the requirements, single/double weighing and high/low speed weighing and measuring systems can be selected. A control system with AI intelligent operation and self-learning is adopted to automatically adjust and optimize parameters, so that the speed and accuracy are in the best state; At the same time, automatic analysis and calculation can be performed based on the accuracy values feedback from the backend belt type weighing system, and the measurement system parameters can be automatically adjusted;

We can provide standard automatic bagging systems and large capacity automatic bagging systems to increase bag storage capacity;

Standard configuration bag length and height automatic adjustment mechanism to meet the production requirements of different product sizes;

Optional sewing machine or sewing machine+heat sealing machine for bag opening sealing;

Adopting a multi axis servo system as the executing mechanism, with automatic adjustment and synchronous control, automatic parameter setting, improving equipment stability and facilitating personnel operation and debugging;

Equipped with a full-color dual touch screen interpersonal interaction interface, the 12 inch main screen adopts a rotating cantilever installation method, which facilitates operators to operate and debug the equipment at different positions, and provides real-time status monitoring, data acquisition, fault diagnosis, and assistance functions;

Configure a vacuum pump and air storage tank system to ensure stable negative pressure and improve the success rate of bagging and bagging;

Configure remote help function, which can automatically restore parameters, modify programs, expand functions, diagnose and troubleshoot faults with customer authorization;

Optional detection technology based on visual AI technology can automatically check the sealing quality and achieve unmanned operation.
