Technical parameters
WHP-3(5)-YT/ WHP-4-HYT Wonton Machine
WHP-3-YT Wonton weight: 4-5g, 8-10g, 12-16g
WHP-4-HYT Wonton weight: 12-16g
WHP-5-YT Wonton weight: 8-10g
Models: WHP-3-YT, WHP-4-HYT, WHP-5-YT
Production capacity: 180-210 pcs/min, 280-320 pcs/min, 320-400 pcs/min
Power: 9.6Kw/10Kw, 12.3Kw, 12.3Kw
Power supply: Three-phase 380V 50Hz/60Hz
Dimensions: 3000X2900X2400mm, 3100X2900X2400mm, 3100X2900X2400mm
Weight: 1600Kg
Product overview
The machine features a fully SUS304 stainless steel sheet metal body with a random-textured, anti-fingerprint finish, exuding a minimalist yet refined industrial design. Its SUS304 stainless steel frame offers superior corrosion resistance, extending equipment lifespan and easing cleaning.
Controlled by servo motors, the central rotating platform can flexibly adjust motion-to-stop ratios per product requirements, enhancing basic performance and enabling precise control.
The controller replaces traditional PLCs with advanced industrial computers, offering high reliability, real-time processing, easy scalability, rich I/O interfaces, and adaptability to harsh industrial environments.
The filling mechanism now uses a servo motor and high-precision imported gear motor instead of a lever-cam setup. Filling weight and timing are adjusted via HMI parameters, ensuring consistent accuracy.
An innovative no-leftover wrapper design ensures complete wrapper usage, preserving craftsmanship and enhancing product taste.
Songchuan's self-developed two-axis robotic arm picks up dough wrappers, matching production speed with flexible adjustments for stable, precise placement onto molds.
