Capacity: 90-100 pcs/min, 120-150 pcs/min

Power supply: three-phase 380V 50Hz/60Hz

Gas source: 11.7Kw, 13.2Kw

Dimensions: 3100x2900x2400mm, 3200X3000X2400mm

Weight: 1600kg

WHP-2-HT dumpling weight: 21-26g, 27-30g, 35-40g

WHP-3-HT dumpling weight: 7g, 8-10g, 12-16g, 17-21g

The machine is made of SUS304 stainless steel sheet metal, and the surface of the body is treated with random patterns

and sprayed with anti fingerprint paint technology, making the appearance of the whole machine show the beauty of

simple but not simple industrial design. The all SUS304 stainless steel frame provides higher anti-corrosion performance,

greatly extending the service life of the equipment and ensuring better cleanliness.

Using servo motors for control, the central control rotating platform can flexibly set different dynamic stop ratios

according to product needs, greatly improving the basic performance of the equipment. Realize precise control for

different products.

The equipment controller no longer uses the traditional PLC control, but adopts advanced industrial computers.

It has the advantages of high reliability, real-time response processing, easy scalability, rich digital and analog input

and output interfaces, and can adapt to harsh industrial field environments.

The filling mechanism no longer uses the traditional lever mechanism with cam transmission, but directly uses servo

motors with high-precision imported reduction motors. The weight and start stop time of the filling can be directly

set on the human-machine interface through parameter settings, ensuring continuous and accurate filling weight.

Adopting an innovative no return design, the entire production process eliminates any residue on the dough,

ensuring that the dough process is not damaged after one use, greatly improving the taste of the product.

The two axis robotic arm independently developed by Matsukawa is used to extract the dough, with a rhythm

speed that follows the production speed of the entire machine and flexible changes. It can stably and accurately

place the dough on the molding mold.
