Packaging speed: 15-40 packs/minute

Packaging specification: Length: 100-250mm

Packaging specification width: 40-150mm

High packaging specification: 20-90mm

Pneumatic source supply: 6Kg/cm²

Net weight of the machine: 500kg

Overall dimensions: 1420x988x1500mm

Power type: 220V 50Hz/60Hz

Packaging materials: OPP/CPP, PT/PE, KOP/CPP aluminum-coated film

Total power: 9Kw

Scope of application: Utilizing prefabricated bags, this system features fully automated bag retrieval, delivery,

opening, material pushing, and bag pushing.

With its compact and aesthetically pleasing structure, it is suitable for packaging pre-packaged food in bags.

Main performance and structural features:

1. Servo control system is adopted, with clearer display on the touch screen human-machine interface and easier maintenance;

2. Automatic material sorting and conveying is adopted, facilitating connection with automatic production lines

and saving labor costs;

3. Photoelectric eye automatic detection and servo tracking are used,

so that bags are not opened when there is a deviation in bag position, maximizing the saving of packaging materials;

4. High degree of automation, strong professionalism, high production efficiency, and low failure rate.
