Production speed: 5-20 packs/minute (depending on box size)

Packaging size: L 100-300mm, W 100-250mm, H 30-120mm

Roll film specification: diameter 260mm, width 500mm

Film material: POF 19um (cross-linked film)

Power supply: single-phase AC 220V 50Hz

Total power: 13.5Kw

Gas source: 0.5 MPa~0.7 MPa

Machine noise: ≤ 75db

Whole machine weight: 1500Kg

Dimensions: 3100mmX1450mmX1800mm

Scope of application: Suitable for lamination of 3C/cosmetics/healthcare/tea/toys and other products.

Performance advantages: The equipment runs efficiently and stably, with smooth and coherent operations,

fast running speed, convenient and time-saving film replacement, effectively reducing downtime losses,

and comprehensively improving overall production capacity; Adopting precision servo positioning

and independent corner cutting mechanism, the four corners are cut neatly, the film is laminated smoothly without bubbles,

and the process is highly visualized; Adopting a touch screen intelligent control system, with one click parameter setting,

reducing the operating threshold.
