Packaging speed: 60 packs/minute

Packaging specification: Length: 100-300mm

Packaging specification width: 40-150mm

High packaging specification: 20-90mm

Pneumatic supply: 6Kg/cm²

Net weight of machine: 500kg

Overall dimensions: 2000x970x1310 mm

Power type: 220V 50Hz/60Hz

Packaging materials: PP/CPP, PT/PE, KOP/CPP aluminum-coated film

Total power: 9Kw

Scope of application: Packaging for small-sized bread, cube toast, pure cake, sealed/four-side sealed and flat-pocket prefabricated bags. Snack foods such as waffles and biscuits, coffee bars, electronic products, cosmetics, cards, and other materials can be packaged in one or two combinations. Packaging for eight-side sealed/four-side sealed and flat-pocket prefabricated bags.

Main performance and structural features: 1. Adopting a servo control system, the touch screen human-machine interface provides clearer display and easier maintenance; 2. Utilizing automatic material sorting and conveying, it facilitates connection with automatic production lines and saves labor costs; 3. Photoelectric eyes for automatic detection and servo tracking prevent bag opening in case of bag position deviation, maximizing the saving of packaging materials; 4. High automation, strong professionalism, high production efficiency, and low failure rate.
