Packaging speed: 5-25 packs/minute

Packaging specification: length: 440-550mm

Packaging specification width: 180-380mm

High packaging specification: 50-130mm

Total power: 6KW

Pneumatic source supply: 6kg/cm²

Net weight of machine: 700kg

Overall dimensions: 2800x1200x1350mm

Power type: 220v 50Hz/60Hz

Packaging materials: OPP/CPP, PT/PE, KOP/CPP aluminum-plated film

Scope of Application：Triangle cakes, triangle bread, sandwiches, etc. can be labeled or taped

Main performance and structural features

1. The adoption of a servo control system results in a clearer display on the touchscreen human-machine interface,

making maintenance easier;

2. Adopting automatic material sorting and conveying, which facilitates connection with automatic production lines

and saves labor costs;

3. The photoelectric eye automatically detects and servo tracks, and does not open the bag

when there is a deviation in bag position, maximizing the saving of packaging materials;

4. High degree of automation, strong professionalism, high production efficiency, and low failure rate.
