Technical parameters
Packaging film width: 90-400mm
Packaging specification length: 80-350mm
Packaging specification width: 35-180mm
High packaging specification: 5-70mm
Packaging speed: 30-120 bags/min
Total power: 5.2kw
Main motor power: 3.1kw
Heating power three temperature control: 2.1kw
Net weight of machine: 650kg
Machine dimensions: 1930x880x1380mm
Power type: 4200x880x1380mm
Packaging film materials: OPP/CPP, PT/PE, KOP/CPP, VMBOPP, VMCPP, VMPET, etc
Product overview
Suitable for packaging various solid and regular objects such as baked goods (mooncakes, bread, cookies, etc.),
medical equipment, candies, medicines, daily necessities, hardware parts, paper boxes or trays.
The whole machine is controlled by six servos.
Seven inch touch screen display, easy to operate, clear and distinct working status;
It can store multiple product parameters and formulas without the need for repeated settings, and can be downloaded and used immediately;
Automatic adjustment of bag length, film breakage detection, photoelectric detection, automatic tracking adjustment of bag length, no need for manual setting;
The higher precision sealing and cutting position of the whole machine is accurate and error free;
The parking position and printing position can be set arbitrarily by clicking, which is convenient and fast;
The mechanical mechanism is simple, the debugging is convenient and intuitive, and the after-sales maintenance cost is low;
The packaging range can be expanded to accommodate multiple product specifications;
Reduce the labor intensity of operators and effectively improve production efficiency;
Equipped with multiple safety protection measures to ensure stable production.
