Load: 30KG

Maximum travel distance of the robot: 1680mm

Packing cycle: ≤15 pieces/min

Carton size: length: ≤600

Carton size width: ≤500

Carton size height: ≤450

Total power: 3Kw

Air pressure source supply: 5kgf/cm², 0.6 MPa

Net weight of the machine: 150Kg

Machine dimensions: Host machine: 2200*500*1100mm / Electric box: 700*320*1200mm

Power type: Single-phase 220V±10%, 50Hz/60Hz

Easy to operate with no foundation required, ready to use upon startup, and convenient to debug;

Small footprint, flexible and maneuverable, easy to drag and drop;

Meet various types of boxes and stacking patterns;

Input basic parameters, choose any stacking pattern, and it can align automatically, without requiring excessive manual settings;

Equipped with mechanical anti-collision features, it offers higher safety and can also be equipped with guardrails or light barriers;

It automatically lifts and lowers according to the stacking height, with a maximum height of 2.5 meters;

Multiple formulas are stored, allowing for easy access and no need for repetitive settings;

24/7 operation, saving time, manpower, and effort;

It is widely applied in various industries, such as food, household paper, beverage, medicine, daily chemical products,

electrical appliances, and electronics.
