Maximum load (KG)：20KG

Working radius (mm)：1880mm

Maximum palletizing time (pcs)：≦12PCS/min

Maximum stacking height (mm)：≦2000mm

Repeated positioning accuracy (mm)：±0.04mm

Pallet arrangement：手动/AGV，一左一右

Maximum fitting tray (mm)：1300mm*1200mm

Equipment appearance size (mm)：L1700mm*W1300mm*H2735mm

Size of wooden box (mm)：L2200mm*W1450mm*H1900mm

Maximum power (KW)：3.0KW

Reference air consumption：240-460L/min

Power supply requirement：单相220V±10%，50Hz/60Hz

Gas supply requirement：0.5～0.7Mpa

Communication mode：TCP/IP  MODBUS TCP 扩展IO

IP level：IP54

Temperature range：0-50°C

Machine weight (KG)：约500kg

Easy to operate with no foundation required, ready to use upon startup, and convenient to debug;

Small footprint, flexible and maneuverable, easy to drag and drop;

Meet various types of boxes and stacking patterns;

Input basic parameters, choose any stacking pattern, and it can align automatically, without requiring excessive manual settings;

Equipped with mechanical anti-collision features, it offers higher safety and can also be equipped with guardrails or light barriers;

It automatically lifts and lowers according to the stacking height, with a maximum height of 2.5 meters;

Multiple formulas are stored, allowing for easy access and no need for repetitive settings;

24/7 operation, saving time, manpower, and effort;

It is widely applied in various industries, such as food, household paper, beverage, medicine, daily chemical products,

electrical appliances, and electronics.
