Maximum load: 25KG

Working radius: 1880mm

Maximum palletizing cycle time: ≦12 PCS/min

Maximum palletizing height: ≦2550mm

Repeatability accuracy: ±0.04 mm

Tray placement form: manual/AGV, one on the left and one on the right

Maximum compatible pallet size: 1300mm*1200mm

Equipment dimensions: L1700mm*W1300mm*H2590mm

Logistics wooden box dimensions: L2200mm*W1450mm*H1900mm

Maximum power: 3.5KW

Reference air consumption: 240-460L/min

Power supply requirements: Single-phase 220V±10%, 50Hz/60Hz

Gas supply requirement: 0.5~0.7 MPa

Communication mode: TCP/IP MODBUS TCP extended IO

IP Rating: IP54

Temperature range: 0-50°C

Overall weight: approximately 550kg

Easy to operate with no foundation required, ready to use upon startup, and convenient to debug;

Small footprint, flexible and maneuverable, easy to drag and drop;

Meet various types of boxes and stacking patterns;

Input basic parameters, choose any stacking pattern, and it can align automatically without requiring excessive manual settings;

Equipped with mechanical anti-collision features, it offers higher safety and can also be equipped with guardrails or light barriers;

Automatically lifts and lowers according to the stacking height, with a maximum height of 2.5 meters;

Multiple formulas are stored, allowing for easy access and no need for repetitive settings;

24/7 operation, saving time, manpower, and effort;

It is widely applied in various industries, such as food, household paper, beverage, medicine, daily chemical products,

electrical appliances, and electronics.
