Equipment model: ZX660C

Packing speed: 5-12 boxes/minute (depending on the product)

Carton specifications: length 270-550mm, width 180-380mm, height 180-400 mm

Sealing method: Tape sealing (48 mm, 70 mm width optional)

Gas source: 0.6-0.8 Mpa, gas consumption: 200 L/min

(the purchaser shall prepare the gas source themselves)

Equipment power: 10 Kw (including material handling line)

Box blank material: corrugated cardboard box

Power type: 380 V ± 10%, 50 Hz ± 5%, control voltage adopts DC 24 V

Whole machine weight: approximately 2000 Kg (including material handling line)

Host dimensions: length 5950mm, width 1850mm, height 2250mm

The whole machine has a compact structure, is stable and reliable, occupies a small area, can be fed on both sides,

has a convenient layout, and is easy to maintain;

The equipment has automatic and accurate box delivery, and will automatically alarm or shut down in case of missing boxes;

When the equipment malfunctions and shuts down, the material will automatically stop being transported, making

it convenient for the staff to solve the problem. The mechanical mechanism of the equipment has overload protection

function and stops. If the equipment experiences overload protection, after manually resetting the overload mechanism,

the button reset should be able to automatically restore the phase of the servo control system (slowly return to the origin);

The sealing part is sealed with tape to ensure a smooth and beautiful seal;

Each cylinder action can be set with manual and automatic selection functions on the touch screen;

All moving parts must have safety protection signs;

The control circuit should use multi-core cables of 1.5 mm ² or more, and the signal circuit should use shielded

 cables of 0.75 mm ² or more without joints. The operation screen should be set on the same plane as the safety

door on the operation side, and the electrical control cabinet should be fixed on the host with reasonable wiring

and easy maintenance;

Replacing the tape requires manual replacement by shutting down the machine;

There are certain requirements for the quality of the cardboard boxes used;

Compared with similar packaging machines in the market:

1. 1.The mechanical arm packaging layout is flexible and highly applicable.

2. 2. It is convenient to adjust specifications during production changes.

3. 3. Small footprint, saving space for customers.
