Equipment model: ZX660R

Packing speed: 5-12 boxes/minute (depending on the product)

Carton specifications: Length: 270-550mm Width: 160-400mm Height: 120-400mm

Sealing method: Tape sealing (48mm, 70mm width optional)

Gas source: 0.5-0.7Mpa, gas consumption: 200L/minute

Equipment power: 14kW (including material handling line)

Box blank material: corrugated cardboard box

Power type: 380V ± 10%, 50Hz ± 5%, control voltage adopts DC 24V

Whole machine weight: approximately 3000kg (including material handling line)

Host dimensions: 7750 × 4600 × 2650mm (including material handling line unpacking machine and sealing machine)

This device adopts servo+PLC precise control, with high positioning accuracy, stable and reliable action, and small repeated positioning error

Strong flexibility in action, can quickly switch product specifications through the program, suitable for multi variety production

Integrating material handling and packing, automatically completing sorting, sorting, grabbing, and packing, reducing manual intervention

Adjustable running speed, high efficiency, fast servo response, can match the rhythm of high-speed production lines

Compact structure, small footprint, replacing traditional mechanical linkages with robotic arms, and more flexible layout

Fault self diagnosis and alarm, PLC real-time monitoring of operating status, easy to quickly troubleshoot and maintain

Human computer interface friendly, touch screen operation, parameter visualization, easy to learn

Smooth operation, low noise, servo drive without impact, minimal damage to products and packaging

Strong scalability, can be connected to conveyor belts, unboxing machines, sealing machines, and palletizing units for fully automatic packaging lines

High stability, long lifespan, suitable for continuous 24-hour industrial production, low maintenance cost
