Packaging speed: 50-100 boxes/min

Model configuration: Eight servo

Molding box length x molding box width x molding box height: L: 130-200mm W: 55-60mm L: 35-80mm

Paper box quality requirements: The paper box should have a pre folding effect, 250-350g/m ²

Power type: Three or four wire phase AC380V50HZ

Motor power: 5.0Kw

Total power: 9.5Kw

Machine dimensions: 4176mm x 1565mm x 1885mm (length x width x height)

(height is the highest and includes the glue spray machine)

Gas consumption: 15L/min

Net weight of machine: 900Kg

Work pressure: 0.6-0.8Mpa

The whole machine adopts eight servo drives, with independent control, feed detection, and glue spraying detection functions;

The machine adopts a sheet metal structure, which is designed smoothly, aesthetically pleasing, and easy to operate;

The whole machine adopts a motion controller, which runs stably and reliably

The touch screen displays real-time operational data, automatically memorizes formulas, switches product storage functions,

and is easy to operate;

Compatible with multiple specifications of paper boxes simultaneously, easy to adjust;

Optional auxiliary functions such as glue spraying, coding, and stamping can be selected;

Dual servo feeding control, stable and precise box loading;

Multiple safety protection measures, fault self diagnosis function, and clear fault display.
