Packaging speed: 30-80 boxes/minute

Model configuration: 9 servo/exterior frosted silver carbon steel

(Molding box) Length: 65-150MM

(Forming box) Width: 25-110MM

(Molding box) Height: 15-60MM

Quality requirements for paper box: The paper box should have a pre-folded effect, with a weight of 250-350g/m²

Power supply type: Three-phase five-wire AC 380V 50HZ

Motor power: 6.05KW

Total power: 10.65KW

Machine dimensions: 4456*1673*1668MM (including feeding tailstock)

Working pressure: 0.6-0.8 MPa

Air consumption: approximately 280~320L/min

Net weight of machine: 950Kg

Nine servo systems, featuring independent control, material feeding detection, and glue spraying detection functions, with a sheet metal structure, boasting a sleek and aesthetic design, and easy to operate

The touch screen displays real-time operational data, with the formula automatically memorizing and switching between product storage functions, ensuring convenient operation

Independent servo rotation for stable and high-success rate box opening, multiple safety protection measures, fault self-diagnosis function, and clear display

It can accommodate multiple specifications of paper boxes simultaneously, and is easy to adjust. Auxiliary functions such as glue spraying, code spraying, and steel stamp coding are available for selection
