Packaging speed: 30-70 boxes/minute

Machine configuration: Eight servo systems

(Molding box) Length: 120-250(mm)

(Forming box) Width: 45-180 (mm)

(Molding box) Height: 30-100 (mm)

Carton quality requirements: The carton must exhibit a pre-folded effect, with a weight of 250-350g/m²

Power supply type: Three-phase five-wire AC 380V 50HZ

Motor power: 4.9 (kw)

Total power: approximately 9.5 (kw)

Machine dimensions: 4262.5x1715x1900(mm)

Working pressure: 0.6-0.8 (Mpa)

Air consumption: approximately 280-320 (L/min)

Net weight of the machine: approximately 900(kg)

Highly efficient automation significantly boosts production capacity, with the entire process of automatic box opening, material loading, folding, and sealing completed seamlessly without human intervention

The packaging specifications can be adjusted according to different products, accommodating various box types and materials, including cardboard, corrugated paper, and laminated boxes

Flexible adjustment, quick switching between product specifications, energy saving and cost reduction, high return rate, and direct reduction in labor costs

A variety of optional configurations are available, including automatic insertion of instruction manuals, complimentary hot melt adhesive, dual-mode sealing with adhesive tape, QR code labeling, or laser marking
