Packaging form: back sealing docking film, back sealing adhesive film

Packaging speed: 720Packs/min (depending on material flowability and bag length)

Bag size: 0.5-3g (other sizes can be customized)

Bag size: Length: 25-85mm Width: 17mm or 20mm (other bag widths can be customized)

Bag pass rate: ≥ 99.7%

Total power: 9Kw

Gas consumption: approximately 0.6Mpa 60L/Min

Packaging materials: Aihua paper, non-woven fabric, DuPont paper, etc

Whole machine weight: approximately 950Kg

Overall dimensions of the machine: 1900x1150x1850mm

Scope of application: This machine is used for automatic bag making and packaging of granular,

block, and sheet materials in various industries such as food, medicine, hardware, chemical, and plastic.

Main performance and structural features:

1. Dedicated control programming control, RV reducer (servo motor) drive, photoelectric tracking;

2. The horizontal sealing mechanism adopts unique technology, integrating sealing, film pulling and other functions;

3. Fully servo motor control, fast packaging speed, low noise, and low energy efficiency.
